Fiberglass tubes for small and large household appliances
2023-05-09 15:34

Product details:

Country of origin:

China

Brand:

Sunbow

Certificate:

UL,Reach,Rohs

Product model:

SB-SGS-40

Due date:

5-7 days after receipt

Payment method:

T/T100%


Model number: SB-SGS-40


Operating temperature: -60~200C


structure


The silicone glass fiber sleeve is made of glass fibre yarn woven into tubes and then coated with silicone insulating oil at high temperature.


Characteristic


Flame retardant: self-extinguishing, abrasion resistance, tear resistance, good compatibility with similar impregnated varnishes, good mechanical performance, soft, insulation.


application


Internal wiring harness of electronics, electrical appliances, automobiles, H and C motors, transformers, inverters, inductors, reactors, generators, heating equipment, lighting, etc.


Technical Parameter

project

performance index

illustrate

breakdown voltage

Minimum average voltage

≥4.0

Before aging

Single Point Minimum Voltage

≥3.0

Minimum average voltage

≥3.0

245±5℃ 6 hours aging

Single Point Minimum Voltage

≥2.0

Heat resistance test

No cracking

OK

245±5℃ 6 hours aging

lame test

VW-1

OK

UL 1441
